16mm White LED Latching Push Button Switch 5–24V DC
16mm White LED Latching Push Button Switch 5–24V DC
Estimated delivery time
Get fastest by
08 Jul 2026
Regular price
₹225.00
Regular price
Sale price
₹225.00
Unit price
per
(
₹
190.68
+ 18% GST Extra
)
Bulk Inquiry?
COD Available
UPI
Cards Accepted
Net Banking
Couldn't load pickup availability
100% Safe Payments
FREE Delivery
GST Billing
Quality Checked
Product Description
- 12v DC Power LED (4.5v to 24v).
- It is an IP65 rated product.
- 4.5 amp loading capacity.
- 5 pin = 1 -LED +,1 – LED -, 1 – COM, 1 – NO, 1 – NC.
- High Quality Stainless Steel Material.
- 3 month replacement Guarantee.
- Mounting Hole Diameter 16mm+.
- Tested for more than 30,000 presses.
- Stainless steel material for long period use.
- In-built round ring illuminated LED.
- Independent LED and Switch Terminals.
- Good Electrical Conductivity.
- Rubber ring and nut for fixing, Waterproof and dustproof.
NOTE :- Latching ON/OFF Type Switch will works as it will be ON on the first press and OFF on the second press.
Product Highlights
- 16mm panel-mount size
- Latching Type operation
- Compatible with 12v DC circuits
- White LED indication
- Stainless Steel body
- IP65 protection rating
Product Specifications
| Mounting size | 16mm |
| Voltage | 12v DC |
| Operation | Latching Type |
| Colour | White |
| Material | Stainless Steel |
| Pin count | 5 pin |
| IP rating | IP65 |
Product Datasheet
Download or view the detailed technical datasheet for this product below.
Product Specifications
| Mounting size | 16mm |
| Locking type ? | Latching type |
| Material | Nickel with Lead Chrome |
| Waterproofing rating | IP65 |
| Operating Voltage | 12v DC (4.5v to 24v) |
| Loading capacity | 4.5 ampere |
| Pinout type | solder pin |
| Number of Pins | 5 |
| Pin type | LED +, LED -, COMMON, NO, NC |
| LED type | Single Color LED |
| Configuration | SPST (one input, & one output) |
| Package Contents | Pushbutton @ 1 nos |
| Datasheet | Download Datasheet |
Bulk Pricing (Excluding GST)
| Quantity | Discount | Unit Price (Excl. GST) |
|---|---|---|
| 10 nos | 5% | ₹ 181.14 |
| 20 nos | 7% | ₹ 177.33 |
| 50 nos | 10% | ₹ 171.61 |
| 100 nos | 12% | ₹ 167.8 |
| 250 nos | 15% | ₹ 162.08 |
| 500 nos | 18% | ₹ 156.36 |
| 1000 nos & more | 20% | ₹ 152.54 |
